The JPZ mobile flood barrier provides highly effective protection for windows, doors, gates and other building openings against water ingress during floods and heavy rainfall.
Its key advantage is almost 100% watertightness, making it one of the most effective mobile flood protection solutions. Thanks to its straightforward operation and adaptability to different opening dimensions, the system offers a practical flood protection solution for residential and commercial properties.
The JPZ mobile flood barrier has been successfully tested for resistance to water leakage and mechanical loading. Its main advantage is the inflatable EPDM seal, which conforms to the surface of the protected opening when pressurised, compensating for minor irregularities along the sealing contact surfaces.
This creates a highly effective barrier against water ingress, helping to maintain watertightness for the required period.
The barrier consists of a permanently installed stainless steel strip and a removable protective panel. When flooding threatens, the panel is simply positioned in the prepared opening, secured using locking pins and sealed by inflating the perimeter seal.
The seal can be inflated using a manual pump or portable compressor. Manual inflation allows the system to operate without an electricity supply. The small amount of air required also enables a rapid response to an impending flood.
Integrated handles and the barrier's relatively low weight make handling easier. Larger versions can also be equipped with hinges or wheels to facilitate movement.
Once the flood risk has passed, the seal can be deflated, the locking pins released and the protective panel removed. After cleaning and drying, the barrier can be stored ready for future use. The protected opening can then return to normal operation.
The removable panel features a durable aluminium frame with an internal infill panel, providing structural support for the sealing system. The frame is supplied in a natural aluminium finish, while the infill panel is finished in white (RAL 9010).
The system also incorporates an inflation valve and a pressure gauge, allowing the seal pressure to be monitored.
The JPZ mobile flood barrier can be adapted to the dimensions of the protected opening. The standard range covers opening widths from 600 to 5,000 mm and water column heights from 300 to 900 mm. Other dimensions and specific requirements can be accommodated upon request.
Standard dimension:
‣ Height 300-1200 mm
‣ Width 500-6000 mm
Other dimensions on request.
‣ Stainless steel strip permanently installed in the opening (window, door or gate)
‣ Removable portable barrier
‣ manual inflator, pressure bottle or CO2 bottle
‣ brackets for hanging
‣ frame made of special Al profiles in natural anodized finish
‣ filling made of Al sandwich sheets in RAL 9010 (white)
‣ inflatable EPDM seals in the profile around the perimeter of the plate
‣ automotive valve for inflating the seal, pressure gauge for checking the pressure in the seal
‣ side plugs or locking pins (the number depends on the size of the protected opening)
‣ handles for easier handling and storage
