The waterproof steel hatch provides reliable protection for access shafts leading to underground utility networks and technical installations against water ingress during rainfall and floods. It is designed for applications requiring watertight protection against high water columns while maintaining quick and safe access to underground facilities. Thanks to its robust construction and high load-bearing capacity, the hatch is also suitable for installation in road surfaces.

Easy and Safe Operation

Opening and closing the hatch is facilitated by a mechanical operating system supported by two gas struts. The operating mechanism can be accessed from both sides, allowing the hatch to be opened from above as well as from inside the shaft. This ensures quick and safe access for maintenance personnel.

The system also includes a dedicated lever for opening and lifting the hatch.

Reliable Watertightness

Watertightness is ensured by an EPDM rubber seal, which protects the access opening against water ingress.

The hatch is designed to protect underground facilities not only during normal rainfall but also against high water columns during floods, making it suitable for applications where reliable watertight protection is essential.

High Load Capacity and Durable Construction

The heavy-duty ribbed construction minimises deflection under both full and concentrated loads. The hatch is designed in accordance with EN 124 and meets the requirements of load class D400, making it suitable for road applications.

The hatch cover is manufactured from AISI 316L stainless steel, while the frame designed for embedding in concrete is made from hot-dip galvanised steel.

Custom Dimensions and Accessories

Waterproof steel hatches are available with internal dimensions ranging from 600 × 600 mm to 1,000 × 800 mm.

Depending on the installation requirements, the hatch can be equipped with safety markings on the hatch cover or Open/Close position markings on the inside of the hatch, helping to improve operational safety and ease of use.

Testing and Proven Quality

Waterproof steel hatches are also designed to protect critical underground infrastructure, where reliable performance is essential.

Before certification, the hatches underwent intensive endurance testing at JaP-Jacina's in-house testing centre in Mnichovo Hradiště, Czech Republic. These tests allowed the structural properties and performance of the hatches to be evaluated under controlled testing conditions.

Product parameters

Features

  • Load capacity of up to 40 tonnes (400 kN)
  • Watertight construction
  • Galvanised steel frame and stainless steel hatch cover

Equipment

  • Central locking mechanism operable from both sides
  • Thermal insulation
  • Anti-slip surface
  • Gas struts
  • Clearly visible Open/Close position indicators

Optional Equipment

  • Custom colour finish for the upper hatch cover
  • Yellow-and-black safety markings
